Xenon/Granit User Guide 311
Standard Connector Pinouts
Note: The following pin assignments are not compatible with Honeywell legacy products.
Use of a cable with improper pin assignments may lead to damage to the unit. Use of
any cables not provided by the manufacturer may result in damage not covered by
your warranty.
40 mil Code 39 in. 15 371.7
cm 38.1 944.1
55 mil Code 39 in. 22.2 461.2
cm 56.5 1171.4
100 mil Code 39 in. 47.5 more than 629.9
cm 120.7 more than 1600.0
100% UPC in. 5.0 85.3
cm 12.7 216.7
7.5 mil Data Matrix in. 3.9 26.9
cm 10.0 68.3
10 mil Data Matrix in. 3.9 35.8
cm 10.0 90.8
55 mil Data Matrix in. 19.2 213.1
cm 48.7 541.2
100 mil Data Matrix in. 35.7 357.2
cm 90.6 907.3
Resolution (1D Code 39) 2 mil (.051mm)
Resolution (2D Data Matrix) 2 mil (.051mm)
Focus (Continued) Full Range (FR)
Symbology (Continued) Near Distance Far Distance
