Performance Series Network Video Recorder User Guide
122
7. Click Apply to save your settings.
8. If you want to save your settings and exit the SETTING menu, click OK.
Configuring Custom Split Settings
Note
This function is only available for
HEN081*4/HEN162*4/HEN163*4/HEN161*4/HEN322*4/HEN323*
4/HEN321*4/HEN642*4/HEN643*4.
Use the Custom Split tab to configure a customized split screen display.
1. Go to Main Menu  SETTING  SYSTEM  DISPLAY  Custom Split.
Figure 10-7 Custom Split Configuration Tab
2. On the Custom Split tab, click + to add the selected split view to the list.
3. Use the mouse to click and drag the display grid to configure it, as needed. You can
combine small squares into a larger display area, or split them up to view more channels
at once.
4. Click Apply to save your settings.
5. If you want to save your settings and exit the SETTING menu, click OK.
Configuring RS232 Settings
1. Go to Main Menu  SETTING  SYSTEM  RS232.
