Honeywell HF Series User Manual

5EN
INSTALLATION (CONTINUED)
7. Cut the Foam Seal (non-adhesive) to the window length. Stuff the Foam Seal (non-adhesive)
between the inner window sash and the outer window glass to prevent air and insects from
getting into room.
Horizontal Sliding Window
Horizontal Sliding Window
Vertical Sliding Window
Vertical Sliding Window
Foam Seal
(adhesive)
Foam Seal
(non-adhesive)
Foam Seal
(non-adhesive)
Window
Sash
Foam Seal
(adhesive)
Window
Sash
8. The Local Air Conditioner is now ready to use.
6. Connect the window bracket to the window.

Honeywell HF Series Specifications

General

Type	Portable Air Conditioner
Fan Speeds	3
Control Type	Electronic
Display Type	LED
Remote Control	Yes
Filter Type	Washable
Power Supply	115V / 60Hz
Refrigerant	R410A
Timer	24-hour
Weight (Indoor Unit)	68 lbs
Dimensions (Outdoor Unit)	N/A (Portable unit, no separate outdoor unit)
Weight (Outdoor Unit)	N/A (Portable unit, no separate outdoor unit)
