Honeywell HF Series User Manual

7
USE AND OPERATION
CONTROL PANEL
FUNCTION BUTTONS
1) Indicator Lights 5) Timer / Temperature Set Controls
2) Power Control 6) Mode Control
3) Filter Reset 7) Timer Control
4) Fan Speed Control 8) Sleep Control
EN
The Power Control turns the unit on and off. When the unit is plugged into an appropriate
electrical outlet, the POWER indicator light will illuminate red indicating the unit is in a Standby
Mode, ready to be switched on at anytime. The air vent will automatically open when the unit is
turned ON and automatically close when unit is turned OFF.
POWER CONTROL
(6) (4) (3) (2)
(1)
(7)(8) (5)
When the operation has reached 250 hours, the Filter Reset light will illuminate.
Switch the Local Air Conditioner OFF and carefully remove filters from the unit and clean. Replace
filters and press the Filter Reset button, the Filter Reset light will turn off and the operation time will
be cleared.
FILTER RESET
4 settings: High, Medium, Low and Auto.
Note: Auto fan speed can be selected in cooling mode only.
FAN SPEED CONTROL

Honeywell HF Series Specifications

General

Type	Portable Air Conditioner
Fan Speeds	3
Control Type	Electronic
Display Type	LED
Remote Control	Yes
Filter Type	Washable
Power Supply	115V / 60Hz
Refrigerant	R410A
Timer	24-hour
Weight (Indoor Unit)	68 lbs
Dimensions (Outdoor Unit)	N/A (Portable unit, no separate outdoor unit)
Weight (Outdoor Unit)	N/A (Portable unit, no separate outdoor unit)
