BOLT AND FASTENER TORQUE INFORMATION
3-2 www.honeywellgenerators.com Honeywell Portable Electrical Generator Service Manual
3.2 BOLT AND FASTENER TORQUE INFORMATION
Component-Specific Fastener Fastener Size
Torque Values
N•m lb. ft.
Alternator End Cover Bolts M5 x 0.75 x 12 4 3
Alternator Housing Bolts M10 x 1.25 x 80 48 35
Axle Bracket Bolts M8 x 1.0 x 16 25 18
Brush Assembly Bolt M5 x 0.75 x 16 2 2
Carbon Canister Bracket Bolts M6 x 1.0 x 10 2 2
Connecting Rod Bolts M8 x 1.25 15 11
Control Panel Bolts M6 x 1.0 x 15 4 3
Cooling Fan Flange Nut
M18 x 1.5
105 77
Crankcase Cover Bolts M8 x 1.25 x 40 28 21
Cylinder Head Bolts M10 x 1.25 x 80 48 35
Exhaust Pipe Bolts M8 x 32 18 13
Fuel Shut-off Valve Hex Fitting M10 x 1.25 24 17
Fuel Tank Mounting Bolts M6 x 1.0 x 25 10 7
Ignition Coil Bolts M6 x 1.0 x 25 10 7
Muffler Cover Bolts M6 x 1.0 x 14 4 3
Muffler Rear Mounting Bracket Bolts M8 x 1.0 x 16 18 13
Muffler Side Guard Bolts M6 x 1.0 x 14 4 3
Oil Drain Screw M12 x 1.5 32 24
Pivot Adjusting Nuts M6 x 0.75 12 9
Pivot Bolts M8 x 1.25 30 22
Rotor Bolt -- 48 35
Spark Arrestor Clamp Screw M4 x 0.75 x 16 1 1
Spark Arrestor Screw M3.5 x 0.75 x 10 1 1
Spark Plug 13/16” 28 21
Starter Solenoid Terminal Nut M6 x 1.0 6 4
Support Leg to Frame Bolts M8 x 1.0 x 16 25 18
Support Leg to Rubber Stopper Bolts M8 x 1.0 x 25 25 18
Wheel Handle Pivot Bracket Bolts M6 x 1.0 x 40 10 7
TABLE 3-3: Torque Values
