Section 3: Programming the Communicator
13
PROMPTS OPTIONS DESCRIPTION
8
Exit Prog. Mode?
(Y/N)_
[Y], [N]
[ESC]
Exits program mode.
Press [N] to go back to Prompt 3.
Press [ESC] to load factory defaults.
Refer to the Exiting Programming Mode paragraph in this section.
9
Comm Path
Choice
(2010 IP & Cell)_
2010 IP & Cell
2013 IP
2013 Cell
2013 IP & Cell
2010 IP
2010 Cell
The Comm Path Choice option is a dual-purposed option. The
selection sets the Comm Paths available to the communicator as well
as the supervision interval and fault times necessary to comply with
the selected edition of the NFPA72 standard.
The two editions of the standard are 2010 and 2013.
The AlarmNet network must hear at least one message from the
device during this supervision period; otherwise, AlarmNet notifies the
central station that a communication failure occurred. This interval
cannot be changed.
The settings that correspond to the choices are:
Choice Supervision Interval IP Fault Time Cell Fault Time
2010 IP & Cell 24 hours 1 hour 1 hour
2013 IP 1 hour 1 hour - - -
2013 Cell 1 hour - - - 1 hour
2013 IP & Cell 6 hours 1 hour 1 hour
2010 IP 5 minutes 5 minutes - - -
2010 Cell 5 minutes - - - 5 minutes
NOTE: Account information is provided by the central station administrator. (Prompts 10-12)
10
Primary City ID
(??)_
[01-99]
Enter the 2-digit primary city ID, 01-99 (decimal).
11
Primary CS ID
(??)
[01-FE]
Enter the 2-digit primary central station ID number, 01-FE (HEX).
12
Primary Sub ID
(????)
[0001-9999]
Enter the 4-digit subscriber account number, 0001-9999 (decimal).
NOTE: Prompts 13 through 17 only appear if the Comm Path Choice is IP, or IP&Cell.
13
IP Flt Time
(60 mins)
[00-60]
This prompt appears only if comm. path includes IP&Cell or IP.
Enter the time delay (1 – 60) in minutes before the
communicator notifies the control there is a communication
path failure over cell. If the panel has an alternate
communication path, a secondary path loss message is sent to
the central station.
NOTE: Refer to table above for
correct default values.
