LTE-CF Installation and Setup Guide
14
PROMPTS OPTIONS DESCRIPTION
14
Cell Flt Time
(60 mins)
[00-60]
This prompt appears only if comm. path includes IP&Cell or Cell.
Enter the time delay (1 – 60) in minutes before the communicator
notifies the control panel that there is a communication path failure to
AlarmNet over the hard-wired Ethernet connection. If the panel has an
alternate communication path, a primary path loss message is sent to
the central station.
NOTE: Refer to table above for
correct default values.
NOTES:
 Changing the IP and Cell comm. path choice defaults the value according to the table in prompt 5.
 The control is notified of the failure after the Cell and/or IP fault times expire.
15
Use DHCP Y/N
(Y)_
[Y], [N]
Dynamically allocates the IP addresses (recommended).
If [N], uses fixed IP addresses.
16
NIC IP Address:
255.255.255.255_
12 digit:
xxx.xxx.xxx.xxx
Enter the 4-part address for this device. The 4 parts of the address
must be separated by spaces (displayed as periods in Review mode).
17
Subnet Mask:
255.255.255.255_
12 digit:
xxx.xxx.xxx.xxx
Enter the 32-bit address mask used to indicate the portion (bits) of the
IP address that is being used for the subnet address. The 4 parts of
the address must be separated by spaces (displayed as periods in
Review mode).
18
Gateway IP Addr:
255.255.255.255_
12 digit:
xxx.xxx.xxx.xxx
Enter the 4-part address assigned to the Gateway. The 4 parts of the
address must be separated by spaces (displayed as periods in Review
mode).
19
DNS Serv IP Addr:
255.255.255.255_
12 digit:
xxx.xxx.xxx.xxx
Enter the 4-part IP address assigned to the DNS (Domain Name
System) server. The 4 parts of the address must be separated by
spaces (displayed as periods in Review mode).
20
Review? Y/N
[Y] = review
[N] = exit
Reviewing Programming Mode Entries
To review the programming options (to ensure that the correct entries
have been made), press [Y]. The programming prompts are displayed
again. Use the up/down arrow keys to scroll through the program
fields without changing any of the values. If a value requires change,
simply type in the correct value.
When the last field is displayed, the “REVIEW?” prompt again
appears.
To exit the programming mode, press [N] in response to the
"REVIEW?" prompt, and refer to Exiting Programming Mode at the
end of this section.
