4-6
DIN Rail Bracket
Spacer Bracket
2x M4 Screws
Secures Midas
®
to
Spacer Bracket
4x M3 Screws
Secures DIN Rail
to Spacer Bracket
Optional Midas
®
DIN Rail Mount
Optional Midas
®
Pyrolyzer Adjustable “L” Bracket Mount
Optional Midas
®
Adjustable “L” Bracket Mount
mounting bracket
screws
Standard Midas
®
Wall Mount
Diagram 4-3. Mechanical installation
Note:
When using the Adjustable
“L” bracket with the High-
Temperature Pyrolyzer
unit, (2) Top Access Tubing
Connectors (MIDAS-A-
031) must be used to insure
proper operation.
Top Access Tubing Connector
(MIDAS-A-031)
honeywell
honeywell
MDA Scientific Midas
PN: MIDAS-E-CDX
SN: 12K-48397
Activate by 24-Nov-12
