SYSTEM OVERVIEW
SYSTEM OVERVIEWSYSTEM OVERVIEW
SYSTEM OVERVIEW
About the Touch Screen Control
General
**IMPORTANT**
If the LYNX Touch is beeping rapidly upon entering the premises, an alarm has occurred during your absence
and an intruder may still be on the premises. LEAVE IMMEDIATELY and CONTACT THE POLICE from a
nearby safe location.
The touch screen icons and keys allow you to control all system functions. Additionally, the touch screen display
shows the zone and description of all system occurrences.
The system also features a built-in sounder, which will sound during alarms and troubles and a built-in speaker
announces system status. Additionally, the system "beeps" during certain system functions, such as during
entry/exit delay times, in Chime mode, and when depressing any of the keys (to acknowledge the key press).
The voice announcement volume is adjustable. The “beeps” that sound in response to alarms always sound at
the maximum volume level however, the volume level for all other “beeps” (trouble, chime, exit/entry, etc) can
be adjusted.
Index Item Description
1 Speaker Source of audible internal warning and confirmation sounds, status announcements, as well as alarms
(see "Summary of Audible Notifications").
2 Home key Used to exit from a screen or return to the Home Screen. Internal LED indicates the following:
Green = System is ready to be armed
Red = System is armed
Green Blinking = System is disarmed, and not ready to be armed (a fault or alarm exists)
Red Steady = System is Armed
Red Blinking = System is in Alarm
Red/Green Blinking alternately = System programming mode OR Two-way voice mode is active
3 Panic key When depressed for 4 seconds, the virtual panic icons are displayed on the touch screen. Internal Red
LED is lit in normal conditions
4 Microphone
Used to record personal messages via the Message Center, and for Two-way Voice operation.
5 Display
Window
Color Liquid Crystal Display (LCD) Touch screen. Displays system status icons, time, system status
information, user menus and the virtual keypad.
