Pinouts
USB Connector
Pin Signal Description
1 VCC +5V USB Power
2 USB2N_A USD D –
3 USB2P_A USB D +
4 DGND USB Power Return
Docking Connector
Pin Definition Pin Definition Pin Definition
A1 GND B1 GND C1 GND
A2 NC B2 DOCKING_LOCK C2 DC_VSYNC_VGA
A3 DC_HSYNC_VGA B3 DC_DATA_VGA C3 DC_CLK_VGA
A4 DC_RED_VGA B4 DC_BLUE_VGA C4 DC_GREEN_VGA
A5 RXD B5 DSR# C5 TXD
A6 RTS# B6 RI# C6 DTR#
A7 CTS# B7 USB_N C7 DCD#
A8 DK_DOCKING_ LOCK_EN# B8 DK_EC_GPIO2_ RESET# C8 USB_P
A9 VA+IN B9 VA+IN C9 DK_DOCKING_3/5V_ POK
A10 VA+IN B10 GND C10 VA+IN
A11 VA-IN C11 VA-IN
7-4
