Installation Instructions MB-Secure 1000/2000/3000/4000/5000/6000 21
3.6 Current consumption of control panel components, detectors
and/or users
The current values specified are approximate values. The values specified for Active Mode are
maximum values - e.g. with LED displays, relays pulled in. The exact total power consumption must be
determined by measurement!
Device
Current consumption at rest / active
Number
Total current
MB-Secure control panel/basic current
See technical specifications
1
IB2 Bus extension
65 mA
IB2 16 I/O extension
See technical data
MB-Secure Siren module(013920)
55 mA / 1.1 A
Flash lamp
See technical specifications
Sirens
See technical specifications
BUS-2/BUS-1 IDENTLOC-EU
9 mA / 9 mA / per LED 3 mA
IDENTLOC sensor (standard range)
(mid. range)
(max. range)
≤5.5 mA
≤10 mA
≤15.5 mA
BUS-2/BUS-1 DUO-I/O module (010120)
5 mA / 45 mA
BUS-2 16-MG blocking/display module (012542) / per LED
25 mA / 5 mA
BUS-2 16-MG display module (012548) / per LED
25 mA / 5 mA
LED keypad (013000)
20 mA / max. 90 mA
LCD keypad (013001)
20 mA / max. 100 mA
BUS-2 Comfort Touch Color operating unit (012575.10)
170 mA / 540 mA
BUS-2 TouchCenter Tuxedo graphical operating unit (013002)
160 mA / max. 310 mA
BUS-2 TouchCenter Plus graphical operating unit (013003/004/005)
140 mA / max. 260 mA
BUS-2 motion detector SCM 3000
3 mA / 8 mA
BUS-2/BUS-1 motion detector Viewguard DUAL AM (033442.20)
4.6 mA / 8.6 mA
BUS-2/BUS-1 motion detector Viewguard DUAL (033443.20)
4.6 mA / 8.6 mA
BUS-2/BUS-1 motion detector Viewguard PIR AM (033432.20)
0.6 mA / 4.6 mA
BUS-2/BUS-1 motion detector Viewguard PIR (033332.20)
0.6 mA / 4.6 mA
BUS-2/BUS-1 smoke detector base module (062090)
3 mA
BUS-2 5-input module (013130.10)
6 mA / 46 mA
BUS-2 5-output module (013131.10)
7 mA / 350 mA
BUS-2 2-relay 2 detector group module (041220)
5 mA / 45 mA
BUS-2 Sounder/flasher with 2 inputs (044500)
4 mA / 80 mA
IDENT-KEY BUS-2 evaluation unit (023312.17)
15 mA / 45 mA (max.) + peripheral
Door controller module (023350.10)
15 mA / 45 mA (max.) + peripheral
IDENT-KEY IK3 operating unit (023320)
15 mA / 50 mA
IDENT-KEY IK3 operating unit (023322)
11 mA / 50 mA
Transmission device DS 7700 (057651.10)
160 mA / 220 mA
Transmission device DS 6700 (057864) / DS 6750 (057865)
135 mA / 155 mA (without Ethernet)
150 mA / 170 mA (with Ethernet)
RF BUS-2 wireless receiver (015600)
15 mA
