Honeywell MM14CCS User Manual

14
WATER DRAINAGE
Continuous Water Drain (De-humidifier Mode)
Your machine is equipped with two drain plugs on the backside, De-humdifier mode and Air Condi-
tioning mode. Water will need to be drained only in two conditions :
• De-humidifier mode
• Air Conditioning mode, when ambient humidity is very high.
Whenever there is excess water accumulation inside the unit, and it needs to be drained. The
machine will stop running and will show an error message. This error message indicates that the
water needs to be drained out using below given procedures :
•
•
•
•
When the unit is running in de-humidifier mode you have to keep
emptying the water stored inside the water tank.
The unit has a threaded drain connection located on the back side
(refer to fig.).
Remove the drain plug, install the drain connector(5/8" universal
female mender) with 3/4" hose(locally purchased).
Once a hose is attached the water drains into the hose. The hose can
then be directed away from the dehumidifier into a floor drain.
Water Drain (Air Conditioning Mode)
•
•
•
•
Your machine is equipped with an Auto-Evaporation System, due to
which no water needs to be drained in Air Conditioning Mode.
However in high humidity areas, you may need to drain water from
this drain plug.
In order to drain water from this drain plug, please open the cap and
place a water tray under the drain plug.
Water will drain out automatically and will be collected in this tray.
Drain Plug
(De-Humidifier
Mode)
Drain Plug
Water Drain Pipe
(AC Mode)

Honeywell MM14CCS Specifications

General

Type	Monobloc mobile air conditioner
Timer	Yes
Timer type	Digital
Hose length	1.2 m
Noise level	53 dB
Hose diameter	127 mm
Refrigerating medium	R410A
Cooling capacity (max)	14000 BTU/h
Dehumidifying capacity	1.875 l/h
Timer duration (maximum)	24 h
Air conditioner functions	Cooling, Dehumidifying, Fan
Suitable for room area up to	46.5 m²
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	-
Display type	LCD
Product color	Black, Silver
Connected load	1500 W
Hourly energy consumption (heating)	- kWh

Weight and Dimensions

Depth	170.18 mm
Width	391.16 mm
Height	635 mm
