Honeywell MM14CCS User Manual

1
2
Plastic Screw
7
INSTALLATION
Push-in Rotate
=
Install the plastic hose with window bracket adapter and hose connector on both sides.
Ensure proper fit on both ends.
Note : Do not install the window
bracket to your window. This step
is required only to adjust it to the
size of your window. The bracket
should be removed from the window
after the size is adjusted.
Adjust the window bracket as per width or height of your window and insert a plastic screw
to fix at the desired position.
Connect the plastic hose to the hose connector on back of the unit.
3
For service questions, contact Honeywell at 1-800-477-0457.
For sales inquiries, contact Sylvane at 1-800-934-9194 or visit
www.sylvane.com.

Honeywell MM14CCS Specifications

General

Type	Monobloc mobile air conditioner
Timer	Yes
Timer type	Digital
Hose length	1.2 m
Noise level	53 dB
Hose diameter	127 mm
Refrigerating medium	R410A
Cooling capacity (max)	14000 BTU/h
Dehumidifying capacity	1.875 l/h
Timer duration (maximum)	24 h
Air conditioner functions	Cooling, Dehumidifying, Fan
Suitable for room area up to	46.5 m²
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	-
Display type	LCD
Product color	Black, Silver
Connected load	1500 W
Hourly energy consumption (heating)	- kWh

Weight and Dimensions

Depth	170.18 mm
Width	391.16 mm
Height	635 mm
