INSTALLATION
It is important that the installation instructions below are followed for successful installation of this
Local Air Conditioner. Please call Customer Support if you have any difficulties or queries
regarding these installation procedures.
Installation Kit:
Installation Steps:
Slide-in the exhaust nozzle to the pre-assembled hose, rotate the exhaust nozzle anti-clockwise,
until it is locked in place. (See Fig. 1).
2.
5
1
x1
x1
x1
2
Through an Open Window
Fig.1
=
Exhaust nozzle adapter, exhaust hose and exhaust hose connector are pre-assembled inside the
package.
1.
1. Flange Fixture + Hole Cover (1 Piece) 4. Exhaust Hose (1 Piece)
2. Exhaust Nozzle Adapter (1 Piece) 5. Exhaust Nozzle (1 Piece)
3. Exhaust Hose Connector (1 Piece)
4
x1
x1
3
