Page 2 of 2 DOC-02-051 Rev. A
© 2009 by Honeywell International Inc. All rights reserved.
Unauthorised use of this document is strictly prohibited.
This document is not intended for installation purposes.
We try to keep our product information up-to-date and accurate.
We cannot cover all specic applications or anticipate all requirements.
All specications are subject to change without notice.
For more information contact your nearest Notier Sales Oce or Distributor
www.notier.com.au
Specications:
Range: 5 to 70m
70 to 100m using optional accessory BEAMLRK
Sensitivity: 25% to 50% Total Obscuration in 6 levels
Level 1 = 25%
Level 2 = 30%
Level 3 = 40%
Level 4 = 50%
Level 5 = 30% to 50% (Acclimate)
Level 6 = 40% to 50% (Acclimate)
Test/Reset Features: Integral Sensitivity Test Filter (FSB-200S only)
Sensitivity Filter (Incremental scale on reector)
Local Alarm Test Switch
Local Alarm Reset Switch
Remote Test and Reset Switch Capability
(compatible with RTS451/RTS451KEY)
Indicators: Alarm: Remote Output, Local LED (red)
Trouble: Local LED (yellow)
Blink Pattern Indicates Trouble Diagnostics
Normal Operation: Local LED (ashing green with communication)
Alignment Aids: Optical Gunsight (coarse adjustment)
00 to 99 Digital Display (ne adjustment)
Relays: Alarm, Trouble
Sensitivity: Digital Display Read-out in Percent Obscuration
Environmental: Temperature: -30°C to 55°C
Humidity: 10% to 93% RH Non condensing
Mechanical: Mounting: Wall only without optional accessories
Adjustment Angle: ± 10° Horizontal and Vertical
Electrical: Voltage: 15 to 32VDC
Average Stand-by: 2mA Max. (1 communication every 5 sec,
LED ashing @24VDC)
Max.Alarm (LED on): 8.5mA
Max. Trouble: 4.5mA
Max. Alignment: 20mA
Ordering Information
FG-03-017 FSB200 Addressable beam smoke detector with 200mm reector
FG-03-018 FSB-200S Addressable beam smoke detector with 200mm
reector and integral sensitivity test
FG-01-064 BEAMMMK Multi-mount kit (Provides ceiling or wall mount
capability with increased angular adjustment)
FG-01-065 BEAMSMK Surface mount kit
FG-01-066 BEAMLRK Long range kit (70m - 100m)
FG-01-067 RTS451Key Remote test station with key lock
