Page 2 of 2 DOC-02-038 Rev. A
© 2009 by Honeywell International Inc. All rights reserved.
Unauthorised use of this document is strictly prohibited.
This document is not intended for installation purposes.
We try to keep our product information up-to-date and accurate.
We cannot cover all specic applications or anticipate all requirements.
All specications are subject to change without notice.
For more information contact your nearest Notier Sales Oce or Distributor
www.notier.com.au
Specications
Normal Operating Voltage: 15 to 32 VDC.
Maximum Current Draw: 6.5 mA (LED on).
Average Operating Current: 350 μA direct poll, 375 μA group poll
with LED ashing, 485 μA Max. (LED
ashing, NAC shorted.)
Maximum NAC Line Loss: 4 VDC.
External supply voltage: Maximum (NAC) Regulated 24VDC.
(between Terminals T10 and T11) Maximum (Speakers) 125 V RMS, 50W.
Drain on external supply: 1.7mA maximum using 24VDC supply.
2.2mA using 80 V RMS supply
Max NAC Current Ratings: 2A
Temperature Range: 0°C to 49°C.
Humidity Range: 10% to 93% non-condensing.
EOL Value: 47K ohms.
Ordering Information
FG-05-024 FCM-1 Single intelligent control (monitored output) module
