26 NFS2-640 UL Listing Document — P/N 52741LD:H9 5/19/2022
The following is a table of detector sensitivity settings by detector type:
Note: If a detectors sensitivity is changed to a value in its Special Applications range, the extended label should be modified at this detector address to
include the phrase `SPECIAL APPLICATIONS' or `SPECIAL APPS'. Refer to the VeriFire Tool help files for more information on extended label pro-
gramming
1 For proper PAS operation, a CGW-MB may not be installed on the network.
NOTE: When programming points, take the following into design consideration:
Each general zone must be dedicated to a single event type (i.e. Fire, MN, Security, etc.)
Map inputs only to general zones designated for the input’s event type. For example, map mass notification devices to general zones designated
for mass notification.
Outputs can be mapped to multiple general zones that are dedicated to different event types. For instance, a single output can be mapped to an
MN general zone and a Fire general zone.
ACS Selection
Group
Annunciator Display
ACS Selection
Group
Annunciator Display
A 8 System points & Zones 1 - 56 M Programmable for use with FireVoice NFV-25/50ZS or First
Command
B Zones 57 - 99, 9 F Zones, 8 R Zones, 4 NACs N 8 System Points & Zones 1-56
C Loop 1, Modules 1 - 64 O 8 System Points & Zones 1-56
D Loop 2, Modules 1 - 64 P* Loop 1, Modules 65-100
Loop 1, Detectors 1-14 (each detector occupies 2 points)
E Loop 1, Modules 65 - 128 Q* Loop 2, Modules 65-100
Loop 2, Detectors 1-14 (each detector occupies 2 points)
F Loop 2, Modules 65 - 128 R* Loop 1, detectors 15-46 (Each detector occupies 2 points)
G Loop 1, Modules 129 - 159 (1 unused point)
Loop 2, Modules 129 - 159 (1 unused point)
S* Loop 2, Detectors 15-46 (Each detector occupies 2 points)
H Loop 1, Detectors 1 - 64 T* Loop 1 Detectors 47-78 (Each detector occupies 2 points)
I Loop 2, Detectors 1 - 64 U* Loop 2 Detectors 47-78 (Each detector occupies 2 points)
J Loop 1, Detectors 65 - 128 V* Loop 1 Detectors 79-100 (Each detector occupies 2 points)
K Loop 2, Detectors 65 - 128 W* Loop 2 Detectors 79-100 (Each detector occupies 2 points)
L Loop 1, Detectors 129 - 159 (1 unused point)
Loop 2, Detectors 129 - 159 (1 unused point)
*Group only available with UDACT programmed as option 2.
Table 5 ACS Selection Groups
NOTE: (d) Signifies the factory default setting in the detector sensitivity table below.
Detector Type Alarm (FlashScan) Alarm (CLIP) Pre-Alarm
Photo Electric
SMOKE (PHOTO)
(See notes
1
and
2
)
AL:1=0.50 %
AL:2=0.73 %
AL:3=0.96 %
AL:4=1.19 %
AL:5=1.43 %
AL:6=1.66 %
AL:7=1.89 %
AL:8=2.12 % (d)
AL:9=2.35 %
AL:1=0.50 %
AL:2=0.73 %
AL:3=0.96 %
AL:4=1.19 %
AL:5=1.43 %
AL:6=1.66 %
AL:7=1.89 %
AL:8=2.12 % (d)
AL:9=2.35 %
PA:1=Auto
PA:2=0.30 %
PA:3=0.47 %
PA:4=0.64 %
PA:5=0.81 %
PA:6=0.99 %
PA:7=1.16 %
PA:8=1.33 % (d)
PA:9=1.50 %
Table 6 Detector Sensitivity (in percent obscuration per foot) (1 of 2)
ACS Address (A1)
ACS Selection Group (H)
ANNUN SELECTION1 A1=H A2=I A3=* A4=*
A5=8 A6=* A7=* A8=* A9=* A10=* A11=*
12 spaces for extended custom label
PROGRM SMOKE(PHOTO) DETECTOR ADDR 1D101
03 __ __ __ __A8P8AV 1D101
Blinking Type Code selection
CBE list
(five zones)
D (detector)
SLC address (001-159)
20-character user-editable custom label (in
this example, autoprogramming has used
the first 19 and left a space at the end.)
SLC Loop number
Alarm sensitivity level
Pre-alarm sensitivity level
Cooperative multi-detector
mode indicator
Alarm verification setting
