14 Applicator Interface Kit Installation Guide
6. From the menu, click System Settings > Manage I/O.
7. Chose Enable from the drop down list for the Applicator.
8. From the menu, click Configure > Printing > Applicator. Choose desired
settings from the drop down lists.
Setting Description
Style I-Style, Z-Style, S-Style
Startprint Level or Pulse
Endprint Mode 0, Mode 1/Type3, Mode2/Type4, Mode3/Type
1, Mode 4/Type 2
Ribbon/Media Low Enables/disables the printer low ribbon alert message.
Enables/disables the printer low media alert message.
Reprint Enables/disables reprinting the last label sent to the
printer (by using the Reprint signal)
Error on Pause Enable this setting to set the “Service Required” signal
when the printer is paused. This setting is supported
by Z-Style only.
Error Port Enables/disables the printer external error port.
RTW Configures the Ready-to-Work indicator on the printer
front panel. Choose from:
• Mode 1 - Signal is asserted low when no events are active
in the System Health Monitor (SHM).
• Mode 2 - Signal is asserted low when the printer motor is
idle.
• Mode 3 - Signal is asserted low when the printer motor is
idle and no events are active in the SHM.
DC 5V Switches REL1com and REL3com between REL1nc,
REL1no, REL3nc and REL3no. Selecting Internal 5V
will switch REL1nc and REL3nc to REL1com and
REL3 com respectively. Selecting External 5V will
switch REL1no and REL3no to REL1com and
REL3com respectively.
Note: Users are not restricted to connect DC 5V to
these lines.
