Honeywell RLV3120

RLV3120
4
Connect either one of the
thermostat wires to the
heater wire and the other
one to the power supply
wire using solderless
connectors for copper
wires.
NOTE: All cables and
connections must conform
to the local electrical code.
Special CO/ALR solderless
connectors must be used
when connecting with
aluminium conductors.
Wiring
2-wire installation
4-wire installation
Power supply
Power supply
