65-0106—2 2
RM7823A
SPECIFICATIONS • ORDERING INFORMATION
Specifications
ELECTRICAL RATINGS, see Table 1:
Voltage and Frequency: 120 Vac (+10/-15%), 50 or
60 Hz (+/- 10%).
2
Power Dissipation: 10 watts maximum.
Maximum Total Connected Load: 2000 VA.
Fusing: Total Connected Load: 20A maximum, type
FRN or equivalent.
TABLE 1—TERMINAL RATINGS.
Terminal No. Description Ratings
G Flame Sensor Ground
Earth G Earth Ground
1
L2(N) Line Voltage Common
3 Line Voltage Supply (L1) 120 Vac (+10/-15%), 50 or 60 Hz (+/- 10%).
2
4 Unused
5 Unused
6 Unused
7 Unused
8 9KA Common
9 9KA1 N.O. 9.8 AFL, 58.8 ALR at 120 Vac
10 9KA2 N.C. 1A Pilot Duty at 120 Vac
F(11) Flame Sensor 60 to 220 Vac, current limited.
12 Unused
13 9KB Common
14 9KB1 N.C. 1A Pilot Duty at 120 Vac; also rated for 5V control circuits.
15 9KB2 N.O. 1A Pilot Duty at 120 Vac; also rated for 5V control circuits.
16 Unused
17 Unused
18 Unused
19 Unused
20 Unused
21 Unused
22 Shutter 120 Vac, 0.5A (RM7823A).
1
The RM7823A must have an earth ground providing a connection between the subbase and the control panel or the equip-
ment. The earth ground wire must be capable of conducting the current to blow the 20A fuse (or breaker) in event of an internal
short circuit. The RM7823A needs a low impedance ground connection to the equipment frame which, in turn, needs a low
impedance connection to earth ground. For a ground path to be low impedance at RF frequencies, the connection must be made
with minimum length conductors having maximum surface areas. Wide straps or brackets rather than leadwires are preferred.
Be careful to verify that mechanically tightened joints along the ground path, such as pipe or conduit threads or surfaces held
together with fasteners, are free of nonconductive coatings and are protected against mating surface corrosion.
2
Operating frequency chosen by RM7823A selection.
Ordering Information
When purchasing replacement and modernization products from your 7800 SERIES distributor, refer to the TRADELINE
®
Catalog for complete ordering
number.
If you have additional questions, need further information, or would like to comment on our products or services, please write or phone:
1. Your local Home and Building Control Sales Office (check white pages of your phone directory).
2. Home and Building Control Customer Satisfaction
Honeywell Inc., 1885 Douglas Drive North
Minneapolis, Minnesota 55422-4386 (612) 951-1000
In Canada—Honeywell Limited/Honeywell Limitée, 740 Ellesmere Road, Scarborough, Ontario M1P 2V9 International Sales and Service Offices
in all principal cities of the world. Manufacturing in Australia, Canada, Finland, France, Germany, Japan, Mexico, Netherlands, Spain, Taiwan, United
Kingdom, U.S.A.
