69-1726—1 12
Step 6. Mount New Wallplate to Wall (Cont)
2. Pass the labeled wires through the wire hole on the
wallplate.
M22279
WIRE HOLE
WALL OPENING
WAL
L
PLATE
LABELED WIRES
