Step 7. Connect Wires to New Wallplate (Cont)
1
M22246
If wires will be connected to both RC and R on the new thermostat,
remove metal jumper wire between R
C and R. Leave metal jumper
wire in place if only one of the terminals, R
C or R, will be connected
on the new thermostat.
If wires were connected to both R and RH terminals on the old
thermostat, remove metal jumper wire between R
C and R on the
new thermostat. Connect the old R to the new R
C and the old RH
to the new R.
If two C and/or C1 wires were connected to the old thermostat, do
not connect them to the new thermostat. Wrap the bare end of
each wire separately with electrical tape and do not use.
If one C and/or C1 wire was connected to the old thermostat, the
wire should be connected to the "C" letter designation on the new
thermostat.
2
3
NOTES FOR CONVENTIONAL HEATING AND COOLING SYSTEMS
4
To Next Page
