SMV 3000 Specifications, continued
Performance Under Rated Conditions - General
Parameter Description
Output (two-wire)
Analog 4 to 20 mA or digital (DE protocol).
Power Supply Voltage Effect
0.005% span per volt.
CE Conformity (Europe)
89/336/EEC, Electromagnetic Compatibility (EMC) Directive.
Physical
Parameter Description
Barrier Diaphragms Material
SMA110
SMA125
SMG170
SS
SS, Hastelloy C, Monel and Tantalum
SS, Hastelloy C,
Process Head Material
SMA110
SMA125
SMG170
Carbon Steel (Zinc-Plated) or 316 SS
Carbon Steel (Zinc-Plated), 316 SS, Hastelloy C or Monel.
Carbon Steel (Zinc-Plated), 316 SS, or Hastelloy C.
Head Gaskets
Glass filled PTFE standard. Viton is optional
Meter Body Bolting
Carbon Steel (Zinc plated) standard. Options include 316 SS, NACE A286
SS bolts and 304 SS nuts and B7M.
Optional Adapter Flange and Bolts
Adapter Flange materials include 316 SS, Hastelloy 276 and Monel. Bolt
material for flanges is dependent on process head bolts material chosen.
Standard flange material is glass filled PTFE. Viton is optional.
Mounting Bracket
Carbon Steel (Zinc-plated) available in angle or flat style.
Fill Fluid
Silicone oil or CTFE (Chlorotrifluoroethylene).
Electronic Housing
Low Copper-Aluminum. Meets NEMA 4X (watertight) and NEMA 7
(explosion-proof).
Process Connections
1/4-inch NPT (Option 1/2-inch NPT with adapter).
Wiring
Accepts up to 16 AWG (1.5 mm diameter).
Dimensions
See Figure 8.
Net Weight
5.3 Kg (11.6 lb)
Mounting
See Figure 9.
Approval Bodies
- Hazardous Conditions
- Canadian Registration Number
(CRN)
- Approved as explosion proof and intrinsically safe for use in Class I,
Division 1, Groups A, B, C, D locations, and nonincendive for Class I,
Division 2, Groups A, B, C, D locations. Approved EEx ia IIC T4, T5,
T6 and EEx d IIC T5, T6 per ATEX standards. See attached Model
Selection Guide for options.
- All ST 3000 amd SMV 3000 model designs, except STG19L, STG99L,
STG170, STG180, have been registered in all provinces and territories
in Canada and are marked CRN: 0F8914.5C.
Pressure Equipment Directive
(97/23/EC)
The ST 3000 pressure transmitters listed in this Specification have no
pressurized internal volume or have a pressurized internal volume rated
less than 1,000 bar (14,500 psig) and/or have a maximum volume of less
than 0.1 liter. Therefore, these transmitters are either; not subject to the
essential requirements of the directive 97/23/EC (PED, Annex 1) and shall
not have the CE mark, or the manufacturer has the free choice of a module
when the CE mark is required for pressures > 200 bar (2,900 psig).
