22
Commissioning
Figure 5.12 Programmable Zone
NOTE: The image above shows the PULSE, COINCIDENCE, and COINCIDENCEx3 menus.
These menus are inactive in this release and will be available only in a future release.
NOTE: If delay is configured for a zone, then the output will remain OFF till the delay period
expires, after the delay is over the output will turn ON.
NOTE: You can also double click any button to set the OFF mode.
