7
Introduction
• Multi-colour touch screen display
• RS485 connections for wiring annunciators
• RS232 connection for printer
• Firmware upgrade or downgrade through USB
• Portable configuration settings (through USB or Bluetooth)
• Backing up the event logs (through USB or Bluetooth)
• Multi-level access control (Level 1, 2, 3, and 4)
• All sounder deactivation via programming
• 315-080 annunciator support
• 315-040 LED driver for customized graphic annunciators
• Auto-learning capability
• Configuration options: USB storage device, mobile app, and the panel interfaces
• 10000 event logs for SMX
• 5000 event logs for STX
• View pulse width (PW) values
• View voltage and analogue values
• Monitored input support for supervisory
• Printer support
• Set date and time
• Walk test
• Zone disablement
• 160 programmable zones
2.2 Standards
Underwriters Laboratories (UL)
• UL 864 (10
th
edition) Standard for Control Units
For standards related information, refer to Underwriters Laboratories (UL) documents.
2.3 User Control Levels
2.3.1 Level Definition
The FACP panel has four user control levels: Level 1, Level 2, Level 3, and Level 4.
At all the four levels, the touch display is the primary indicator for the status of installation
and provides detailed information about any current fire alarm, trouble, test, or disablement
condition.
USER LEVEL 1 - All the front panel displays are functional except the control keys.
USER LEVEL 2 - All front panel controls are functional. Some system operation parameters
and functions can be changed. User Level 2 is accessible by entering a passcode from level
1. Maximum 10 users with unique passcodes can be programmed in the panel.
NOTE: The default passcode for LEVEL 2 is 1234.
