Honeywell T2798I2000 - MODE AND SENSOR SETTINGS; Mode Setting Configuration; Sensor Setting Configuration

Page 14 of 18 APHITEMPCON001-11-04
The range is 3.0 to –3.0 °C.
- Press “ENTER” key to save the setting value.
P V : 3 0 . 2 ° C
O F F S E T - 1 . 0 ° C
Fig. 6
7. Mode Setting:
- Press “SELECT” to choose “MODE Setting”, the display will show as in fig.7
- Press key one time to step up. The total number of modes is 6. It will stop
incrementing at last mode i.e. H/AL mode.
-
MODES: Output 1 function: Output 2 function:
COOL Cooling No Function
HEAT Heating No Function
C/H Cooling Heating
H/C Heating Cooling
C/AL Cooling Low Temp. limit Alarm
H/AL Heating High Temp. limit Alarm
- Press key one time to step down. The total number of modes is 6. It will stop
decrementing at first mode i.e. COOL mode.
- Press “ENTER” key to save the setting value.
-
P V : 3 0 . 2 ° C
M O D E C O O L
Fig. 7
8. Sensor setting :
- Press “SELECT” to choose “Sensor Setting”, the display will show as in fig. 3
- Press key one time to switches from INT to EXT.
INT : Internal sensor
EXT : External sensor
- Press key one time to switches from EXT to INT.
- Press “ENTER” key to save the setting value.
P V : 3 0 . 2 ° C
S E N S O R I N T
Fig. 8
