Honeywell T2798I2000 - ADVANCED SETTINGS; Reverse Action Setting; Display Setting; Manual Operation Setting

Page 15 of 18 APHITEMPCON001-11-04
9. Reverse Action Setting :
- Press “SELECT” to choose “Reverse Setting”, the display will show as in fig. 9
- Press key one time to switches from OFF to ON.
OFF : Output1 in normal mode, i.e. 2 - 10Vdc or 4 - 20mA
ON : Output in reversing mode, i.e. 10 - 2Vdc or 20 - 4mA.
- Press key one time to switches from ON to OFF.
- Press “ENTER” key to save the setting value.
P V : 3 0 . 2 ° C
R E V E R S E O F F
Fig. 9
10. Display Setting :
- Press “SELECT” to choose “Display Setting”, the display will show as in fig.10
- Press key one time to switches from OFF to ON.
OFF : Normal mode, as shown in fig. 2.
ON : Percentage mode, output1 is percent value (2Vdc or 4mA – 0% & 10Vdc
or 20mA – 100%) as shown fig.11.
- Press key one time to switches from ON to OFF.
- Press “ENTER” key to save the setting value.
P V : 3 0 . 2 ° C
D I S P L A Y O F F
Fig. 10
P V : 3 0 . 2 ° C
A 0 : 9 1 %
Fig. 11
11. Manual Setting:
- Press “SELECT” to choose “Manual Setting”, the display will show as in fig.12
- Press key one time to switches from OFF to ON.
OFF: Manual OFF
ON : Manual ON
- Press key one time to switches from ON to OFF.
- Press “ENTER” key to save the setting value.
- If manual on, the display will show as in fig.13
P V : 3 0 . 2 ° C
M A N U A L O N
Fig. 12
P V : 3 0 . 2 ° C
A 0 : 9 1 %
Fig. 13
