7 69-1332—3
KEYBOARD AND DISPLAY DESCRIPTION
Keyboard
The keyboard is located behind the thermostat cover. Three frequently used keys, increase ▲ or decrease ▼
and , are located next to the display. See Fig. 1.
Display
The thermostat displays important information such as day, time, schedule period, temperature, filter information,
system and fan operation. See Fig. 2.
