Honeywell Tema-Voyager Multi VMC-04WENN1 - Jumpers

60
TB12 Reader4
TB13 Configurable I/O line 5
TB14 Configurable I/O line 6
TB15 Configurable I/O line 7
TB16 Configurable I/O line 8
Table 6 Terminal blocks
Jumpers
The below table lists the Jumpers and explain their meaning.
Jumper Meaning
P01 External tamper
P02 Console serial line
P03 Configurable Output 4 relay selector
P04 Fixed Output 4 relay selector
P05 Fixed Output 4 relay selector
P07 Fixed Output 3 relay selector
P08 Fixed Output 3 relay selector
P09 Fixed Output 2 relay selector
P10 Fixed Output 2 relay selector
P11 Fixed Output 1 relay selector
P12 Fixed Output 1 relay selector
P13 Configurable Output 3 relay selector
P14 Configurable Output 3 relay selector
P15 Configurable Output 8 relay selector
P16 Configurable Output 8 relay selector
P17 Configurable Output 7 relay selector
P18 Configurable Output 7 relay selector
P19 Configurable Output 2 relay selector
P20 Configurable Output 2 relay selector
P21 Configurable Output 6 relay selector
P22 Configurable Output 6 relay selector
P23 Configurable Output 5 relay selector
P24 Configurable Output 5 relay selector
P25 Configurable Output 1 relay selector
P26 Configurable Output 4 relay selector
P27 Configurable Output 1 relay selector
P29 Reader 1 Wiegand/OSDP selector
P30 Reader 2 Wiegand/OSDP selector
P31 Reader 1 Wiegand/OSDP selector
P32 Reader 1 Wiegand/OSDP selector
