VISIONPRO® 8000 SMART THERMOSTAT
33-00096—04 12
207 Cool Stages /
Compressor Stages
0
1
2
3
1 if ISU 101 is
Residential
2 if ISU 101 is
Commercial
Both Conventional:
Cool Stage 3 is only available if ISU 101 is
Commercial.
Cool Stage 3 must be wired to the U1 terminals.
Heat Pumps:
Maximum of 2 Compressor Stages for heat pump
systems.
202,
207
Heat / Radiant /
Backup Heat Stages
1 - 3
Default is 1 stage if
ISU 101 Application is
Residential
Default is 2 stages if
ISU 101 Application is
Commercial
Both Maximum of 3 stages for conventional systems.
Maximum of 3 stages for radiant heat.
Maximum of 3 stages for Primary Heat. (Heating
system, ISU 200 is set to “Other.”)
Maximum of 2 Backup Heat Stages for systems with
more than 1 heating equipment type.
NOTE: Depending on the application, the text
displayed on the screen may show
the specific heating equipment type.
208 Cool Stage 3
None
U1
Default varies based
on previous selections
Commercial Cool Stage 3 is only available if ISU 101 is
Commercial.
Cool Stage 3 must be wired to the U1 terminals.
U1 are normally open dry contacts when configured
for a stage of Cool. U1 requires power from a system
transformer or a separate transformer.
210 Heat Stage 3
None
U1
Default varies based
on previous selections
Both Heat Stage 3 must be wired to the U1 terminals.
U1 is a normally open dry contact when configured
for a stage of Heat. U1 requires power from a system
transformer or a separate transformer.
211 Fan Control in Heat
No Fan
Equip Controls Fan
Tstat Controls Fan
Equip Controls Fan Both No Fan is only displayed when ISU 201 Heating
Equipment is Other.
212 Backup Heat Type
None
Electric
Gas/Oil
None Both This ISU is only displayed when ISU 200 Heating
Equipment is Radiant Heat or Other.
When ISU 200 Heating Equipment is Radiant Heat,
the thermostat keeps the Radiant Heat on when it
calls for Backup Heat.
When ISU 200 Heating Equipment is Other, you can
select how the backup operates. See ISU 215.
213 Backup Heat Stages
0 - 2
1 Both This ISU is only displayed when a backup heat source
is selected at ISU 212 Backup Heat Type.
Maximum of 2 Backup Heat stages.
214 Backup Heat Stg 2
None
U1
Default varies based
on previous selections
Both The thermostat supports up to 2 backup heat stages.
When there are 2 backup heat stages, backup heat
stage #2 must be wired to U1.
U1 is a normally open dry contact when configured
for a stage of Heat. U1 requires power from a system
transformer or a separate transformer.
Table 2. Installer Setup (ISU) Table. (Continued)
ISU
Number
Installer Setup
Name Settings Default
Residential,
Commercial
or Both Notes
