V9055A,D MODULATING FLUID POWER GAS VALVE ACTUATOR
60-2311-11 2
ORDERING INFORMATION
When purchasing replacement and modernization products from your TRADELINE® wholesaler or distributor, refer to the
TRADELINE® Catalog or price sheets for complete ordering number. If you have additional questions, need further information,
or would like to comment on our products or services, please write or phone:
1. Your local Honeywell Environmental and Combustion Controls Sales Office (check white pages of your phone directory).
2. Honeywell Customer Care
1885 Douglas Drive North
Minneapolis, Minnesota 55422-4386
3. http://customer.honeywell.com or http://customer.honeywell.ca
International Sales and Service Offices in all principal cities of the world. Manufacturing in Belgium, Canada, China, Czech
Republic, Germany, Hungary, Italy, Mexico, Netherlands, United Kingdom, and United States.
SPECIFICATIONS
Models:
V9055A: Modulating Fluid Power Gas Valve Actuator.
V9055D: Modulating Fluid Power Gas Valve Actuator with
proof-of-closure switch.
Low-Fire Adjustment: 0.14 inch to 0.65 inch (with respect
to V5055/V5097B Valve) valve stem travel. Refer to form
70-8311 for valve flow (capacity) curves.
Table 1. Pressure Ratings of Actuator-Valve Combinations.
a
Max Operating Pressure Differential (UL) or Max Operating Pressure (CSA); maximum allowable pressure drop from inlet to
outlet for proper operation.
b
Max rated pressure (UL) or Max Close-off Pressure (CSA); maximum pressure that the valve can be exposed to without leak-
age or damage to the valve.
c
Applies for small-body V5097 valves 3/4” up to 2” pipe size.
d
Applies for large-body V5097 valves 2” up to 3” pipe size.
e
V5055A, B, C only.
Table 2. Electrical Ratings. Table 3. Auxiliary and Proof-of-Closure
Switch Ratings: 1/2 hp
a
.
a
Maximum total connected power to both switches (if used) is
1800 VA.
Opening Time:
50 Hz models: 32 seconds (nominal).
60 Hz models: 26 seconds (nominal).
Closing Time: 1 second (maximum)
Model Pipe Size
STANDARD PRESSURE ACTUATORS V9055A, D
M.O.P.D.
a
Max. Rated Pressure
b
STANDARD PRESSURE VALVES
V5055A, B, C, F, V5097A, B, C
3/4” to 1-1/2”
c
5 PSI 340 mbar 15 PSI 1.0 Bar
2” to 3”
d
5 PSI 340 mbar 15 PSI 1.0 Bar
4” flanged
e
3 PSI 207 mbar 15 PSI 1.0 Bar
HIGH PRESSURE VALVES V5055D,
E, V5097D, E
3/4” to 1-1/2”
c
5 PSI 340 mbar 75 PSI 5.0 Bar
2” to 3”
d
5 PSI 340 mbar 45 PSI 3.0 Bar
Voltage/
Frequency
Opening Holding
Watts VA Watts VA
120/60 60 122 20 32
100-50/60 57/46 100/81 25/20 36/31
220/50 68 141 20 32
240/50 88 194 19 36
120V 240V
Full Load 9.8A 4.9A
Locked Rotor 58.8A 29.4A
