Honeywell Voyager 1202G Quick Start Guide

Out-of-Stand Modes/CodeGate
®
Activation
When the scanner is in the stand, bar codes are automatically read
when they are in the scanner’s field of view. When the scanner is out
of the stand, by default you must push the button on top of the
scanner to read a bar code. Use the following commands to adjust
how the scanner behaves when it is out of the stand.
Presentation Mode Out-of-Stand: When the scanner is not in the
stand, it automatically detects bar codes, then scans and transmits
the data. The laser turns off afterward.
Presentation Mode with CodeGate Out-of-Stand: When the
scanner is not in the stand, it automatically detects bar codes and
decodes them. However, the data is not transmitted until you press
the button. The laser remains on briefly after the transmission.
Reread Delay
This sets the time period before the scanner can read the same bar
code a second time. Setting a reread delay protects against
accidental rereads of the same bar code.
Presentation Mode
Out-of-Stand
Presentation Mode
with CodeGate
Out-of-Stand
Medium Reread Delay

Honeywell Voyager 1202G Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Scanner type	1D
Pitch reading angle	60 - 60 °
Linear (1D) barcodes supported	-
Wireless range	10 m
Bluetooth version	2.1+EDR
Operating frequency	2.4 - 2.5 MHz
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Battery life	12 h
Charging time	4 h
Input voltage	5 V
Battery capacity	1800 mAh
Power source type	Battery
Number of reads per charge	45000
Product color	Black
International Protection (IP) code	IP42
Storage temperature (T-T)	-5 - 35 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	180 mm
Width	66 mm
Height	92 mm
Weight	180 g
Base weight	185 g
Base dimensions	200 x 67 x 97 mm
