CANOPY INSTALLATION
16. Lift the canopy up so the partially installed mounting
bracket screws engage the J-slots on each side of
the canopy. Rotate the canopy clockwise and install
the previously removed mounting bracket screws
from Step 4. Tighten all four screws with a Phillips
screwdriver (Fig. 16).
Mounting
Bracket
Canopy
Fig. 16
Mounting Bracket
Screw
Mounting
Bracket Screw
