Honeywell Xenon CCB01-010BT User Manual

12
Streaming
Presentation™
When in Streaming Presentation mode, the scanner leaves the
scan illumination on all the time and continuously searches for
bar codes.
Suffi
x
Streaming Presentation Mode
If you want a carriage return after the bar code, scan the Add
CR Suffix bar code. To add a tab after the bar code, scan
the Add Tab Suffix bar code. Otherwise, scan the Remove
Suffix bar
code to remove the suffixes.
Add CR Suffix
Add Tab Suffix
Remove Suffix

Honeywell Xenon CCB01-010BT Specifications

General

Device Type	Barcode Reader
Model	Xenon CCB01-010BT
Connectivity	Bluetooth
Operating Temperature	0°C to 50°C (32°F to 122°F)
IP Rating	IP41
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Battery Life	Up to 14 hours
Battery	Lithium-ion battery
Decode Capability	1D, 2D
Drop Specification	1.8 m (6 ft) to concrete
Compatible Barcode Reader	Honeywell Xenon 1902g
Communication Interface	USB, RS232
Power Source	Rechargeable battery
