Installing the XLS-REL
1.14 XLS-REL Technical Reference Manual
Wiring the XLS-REL
Observing equipment and personal safety
To ensure safety with the XLS-REL:
1 Copy Figure 1-7.
2 Cut out the photocopied warning along the perforated line.
3 Post the warning next to the XLS-REL.
4 Inform all appropriate personnel about the posted warning, its
location, and its importance.
5 Require compliance with the warning during all installation
and service procedures.
Warning! Observe static-sensitive material handling practices
while installing or servicing the XLS-REL. Electrostatic
discharge may damage the equipment and activate the release
circuits.
Running the wires
Wire the XLS-REL according to Figure 1-8.
