XLS-REL Technical Reference Manual 2.3
Programming the XLS-REL
Caution! Do not use the Accept Actual function in the Signature
Mapping tool. Accepted data may corrupt the database by causing
it to see every device as two devices.
Warning! DO NOT configure the third and fifth SIGA-UM
addresses as common outputs or audio amplifiers. Any off-
normal condition will activate the automatic release sequence if
these addresses are common outputs. The Drill switch will
activate the prerelease and the release circuits if they are audio
amplifiers. You must select the device types and personality
codes exactly as prescribed in Tables 2-1 and 2-2.
*Actual addresses in your system may differ, but they must be
consecutive. Serial numbers must also be consecutive up to the
second-to-last digit.
**Select one of the following: DamperControl, DoorControl, or
FanControl. Ensure that the selected device type is exclusive for
XLS-REL use.
Table 2-1: Device type selections
Typical address Typical serial number Device type Model
7* 5300411525* Monitor SIGA-UM
8* 5300411532* Pull SIGA-UM
9* 5300411549* DoorControl** SIGA-UM
10* 5300411556* None SIGA-UM
11* 5300411563* DoorControl** SIGA-UM
12* 5300411570* None SIGA-UM
Table 2-2: Device type personality codes
Typical address Personality code
7* 3 N/O Active - Non-Latching (Class B)
8* 1 N/O Alarm Latching (Class B)
9* 16 Signal Output (Class B)
10* 0 No personality
11* 16 Signal Output (Class B)
12* 0 No personality
