Default = IR Trigger mode.
Button and LED Indicator Location
Motion Sensor Mode
When the button is pressed for more than 5 seconds, the scanner will
go into Virtual Global Shutter mode. Virtual Global Shutter mode
promotes motion tolerance performance and the illumination will
flicker. When the button is pressed for 5 seconds again, the scanner
will go into Rolling Shutter mode. While in Rolling Shutter mode, the
illumination will remain on. Default = Virtual Global Shutter mode.
Mobile Phone Read Mode
When the button is quickly pressed, the scanner will go into Mobile
Phone Read Mode. In this mode your scanner is optimized to read
bar codes from mobile phone or other LED displays. When the
button is quickly pressed again, the scanner will exit Mobile Phone
Read Mode.
Right Blue LED Good Read
Left Blue LED Error
Button/Green
LED
Button See Motion Sensor Mode
Green LED Mobile Phone Read Mode activated
Left Blue LED
Right Blue LED
Button/Green
LED
To Next Page
