Hoover UH70805RM User Manual

11
4.20
4.18
4.18 Turn tool so bottom faces up. Rotate the
latches (A) on either side of tool.
4.19 Remove bottom plate (B).
4.20 Remove any debris and/ or hair from brushroll.
Replace bottom plate by aligning tabs along front
edge of tool. Rotate latches back into locked position.
A
4.19
B
HOSE: How to Clean
4.17
A
4.17 To remove hose for tool use, press the hose release button (A) and pull
hose end out.
Clear away debris or obstructions from hose. Do not use sharp objects to clean
out hose as they can cause damage. To lock back into place, push hose into
hose tube until you hear a click.
BRUSHROLL: How to Clean
4.13 Depress handle release pedal and place
handle in low position. Lay vacuum down in
hortizontal position with nozzle facing down as in
Fig. 4.14. Remove (4) screws on nozzle lid.
4.14 Pivot off nozzle cover.
4.15 Remove any debris and/or hair from brushroll
(A).
4.16 Reposition nozzle plate cover and insert (4)
screws.
4.13
4.14
4.15
CAUTION
! !
CAUTION
! !
To reduce the risk of injury from moving parts
- Unplug before servicing.
To reduce the risk of injury from moving parts
- Unplug before servicing.
Actual model may vary from images shown.
A
4.16
WARNING
! !
To reduce the risk of personal injury
- Unplug before cleaning or servicing.

Hoover UH70805RM Specifications

General

Style	upright vacuums
Color	gray
Floor Type	carpet, bare floor
Dust Bin Capacity	0.4 gallons
Cord Length	25 feet
Carpet Height Adjustments	yes
Automatic Cord Rewind	no
Filter	hepa media, reusable
Washable Filter	yes
Pet Mode	no
Hypoallergenic	no
Brush Roll Shut-Off	no
Bagless	yes
?leaning Area	13.5 inches
Brushes and Accessories	turbo tool; crevice tool; dusting brush
Voltage	120 volts
Current	11 amperes

Weight and Dimensions

Length	13 inches
Height	44 inches
Width	14 inches
Net Weight	17 pounds
