MAN0878-09-EN_XLE_XLT_UserManual
A u g u s t 2 3 , 2 0 1 8 P a g e 14 | 158
2.3 Features of XLE/XLT
The XLE/XLT is an all-in-one industrial control device. It combines control, user interface, I/O
and networking into a single, integrated package. Unique features of the XLE/XLT include:
• Bright, graphical LCD display (in XLE) (with touch sensing in XLT)
• Display of complex graphical objects including trends, gauges, meters and animations
• Advanced control capabilities including floating point, multiple auto-tuning PID loops
and string handling capabilities
• Removable media for up to two terabytes of storage of programs, data logging or screen
captures
• CsCAN networking port (optional) for communication with remote I/O, other controllers
or PCs.
• Ethernet version (XLEe/XLTe) with native Ethernet for communication with other
controllers, drives, PCs, etc.
• Configurable serial protocols for communication to drives, PLCs, or other serial
peripherals.
• USB 2.0 full speed port for programming and monitoring.
• Full featured, built-in I/O including high resolution analog, thermocouple, RTD, high-
speed counters, PWM outputs, and relays (depending upon the XLE/XLT model used).
• Cscape programming software that allows all aspects of the XLE/XLT, XLEe/XLTe to be
programmed and configured from one integrated application.
• Optional communication add-on modules that allow additional capabilities such as
Ethernet (pre rev TA only) or modems.
• Fail – Safe System which allows an application to continue running in the event of “Soft”
failures such as (Battery power loss or Battery Backed register RAM / Application Flash
corruption)
• Clone Unit allows the user to “clone” the OCS of the exact same model. This feature
“clones” application program and unit settings stored in Battery backed RAM of an OCS.
It can then be used to clone a different OCS (exact same model).
