HORNER HE-XE100 User Manual

MAN0878-09-EN_XLE_XLT_UserManual
A u g u s t 2 3 , 2 0 1 8 P a g e 90 | 158
Sync mode selection Waveforms (Clockwise Rotation )
__________________________________________________________________
[1]
[2]
High, Reset on 2 rising [SYNC]
High, Reset on 1 falling [SYNC]
High, Reset on 2 falling [SYNC]
High, Reset on 1 rising [SYNC]
*While not displayed in this figure, modes for low level (inverse logic) are also supported
for each state.
Figure 12.1 – Sync pulse mode illustration

HORNER HE-XE100 Specifications

General

Brand	HORNER
Model	HE-XE100
Category	Controller
Language	English
