HORNER XLE-Model 2 Instructions

Wiring:Model 2
Page 5
WIRING: INPUTS AND OUTPUTS
Analog Inputs Information
Rawinputvaluesforchannels1-4arefoundintheregisters
asInteger-typedatawitharangefrom0–32000.

AnaloginputsmaybefiltereddigitallywiththeFilterCon-
stantfoundintheCscapeHardwareConfigurationforAna-
logInputs.Validfiltervaluesare0-7andactaccordingto
thefollowingchart:
Data Values
InputMode: DataFormat,12-bitINT:
0-20mA,4-20mA 0-32000
0-10V 0-32000



Digital Inputs
DigitalinputsmaybewiredineitheraPositiveLogicorNeg-
ativeLogicfashionasshown.ThesettingintheCscape
HardwareConfigurationfortheDigitalInputsmustmatch
thewiringusedinorderforthecorrectinputstatestobe
registered.NojumpersettingsarerequiredforXLEe/XLTe.
Whenusedasanormalinputandnotforhighspeedfunc-
tions,thestateoftheinputisreflectedinregisters%I1–
%I12.








Relay Life
WARNING:Exposuretosomechemicalsmaydegradethe
sealingproper-tiesofmaterialsusedintheTycorelayPCJ.
Cover/Case & Base:MistubishiengineeringPlasticsCorp.
5010GN6-30or5010GN6-30M8(PBT)
Sealing Material:Kishimoto4616-50K(Ipartepoxyresin)


Jumper Settings for Model 2
LocationofI/Ojumpers(JP1&JP2)andwiringconnectors
(J1&J2)withbackcoverremoved.


NOTE:TheCscapeModuleConfigurationmustmatchthe
selectedI/O(JP)jumpersettings.
NOTE:WhenusingJP2(A1-A4),eachchannelcanbeinde-
pendentlyconfigured.

Back Panel Torque Ratings
XLE/XLT:3.0-4.0in-lbs(0.34-0.45N-m)
XL4/XL4 Prime:3.0-4.0in-lbs(0.34-0.45N-m)
EXL6/XL6 Prime:3.0-4.0in-lbs(0.34-0.45N-m)
EXLW/ XLW Prime:3.0-3.5in-lbs(0.34-0.40N-m)
XL7/XL7 Prime:3.0-3.5in-lbs(0.34-0.40N-m)
EXL10/XL10 Prime:3.0-3.5in-lbs(0.34-0.40N-m)


