Hoshizaki KM-1301SWH/3 Service Manual

10
Evaporator Assembly
Spray Tubes
Inlet Water Valve
Water Supply Inlet
Hot Gas Valve
Junction Boxes
Receiver
Check Valves
(refrigeration)
Control Box
Liquid Line Valve
Drier
Control Switch
Bin Control Thermostat
Compressor
Cleaning Valve
Float Switch
Water Pump
Check Valve
(water)
Thermostatic
Expansion Valves
Low-Side Service Valve
High-Side Service Valve
High-Side Liquid Service Valve
Access Valve
3. Remote Models (SRH/3)
Model Shown: KM-1301SRH3
Note: KM-2500SRH3 Includes Headmaster (C.P.R.)
Transformer Box (KM-1301SRH
Auxiliary Code D-1 and Later and
All 3 phase model)

Hoshizaki KM-1301SWH/3 Specifications

General

Brand	Hoshizaki
Model	KM-1301SWH/3
Category	Ice Maker
Language	English
