56
8. Float Switch Selector (S5 dip switch 1): "G" Control Board
NOTICE
Do not adjust. This must be left in the factory default position or the icemaker will
not operate correctly.
9. Rell Counter (S5 dip switch 2 through 5): "G" Control Board
NOTICE
Do not adjust. These must be left in the factory default position or the icemaker will
not operate correctly.
D. Control Switch
The control switch has three positions: "OFF" for power off, "ICE" for icemaking, and
"WASH" to energize the pump motor when cleaning and sanitizing.
