11
B. KMH Construction
1. Water-Cooled Models (SWH/3)
Evaporator Assembly
Spray Tubes
Inlet Water Valve
Float Switch
Water Pump
Water Supply Inlet
Junction Box
Water Regulating Valve
Check Valves
(refrigeration)
Control Box
Liquid Line Valve
Drier
Transformer Box
(3 phase model)
Control Switch
Bin Control Thermostat
Compressor
Cleaning Valve
Thermostatic
Expansion
Valves
Water-Cooled Condenser
Low-Side Service Valve
High-Side Service Valve
Hot Gas Valve
High-Pressure Switch
Check Valve
(water)
Model Shown: KMH-2000SWH3
Model Shown: KMH-2000SWH3
