100
B. Wiring Diagrams
1. "E" and "G" Control Board Schematics without Harvest Pump Timer Relays
a) KM-1601SWH, KM-1601SRH, KM-1900S_H, KMH-2000S_H
*
Control Transformer
Output 10.5V at 115V
* High-Pressure Switch
Water-Cooled Model Air and Remote Model
Cut-out 384±
22
PSIG 412±
22
PSIG
Cut-in 284±22 PSIG 327±22 PSIG
0 0
