21
1. Bin Full
Within 10 sec. after ice contacts
TBC bulb, icemaker shuts down.
Shutdown
and Restart
TBC
Operation
Ice contacts TBC bulb
2. Icemaker Off
All components
de-energized.
3. Ice Level Lowered
No ice touching TBC bulb.
Icemaker starts at
"1. 1-Minute Fill Cycle."
TBC closed
TBC open
All components
de-energized
To 1. 1-Minute Fill Cycle
NOTE: "G" control board green "BC CLOSED" LED
on continuously when the K4 jumper is in place.
3a. Thermostatic Bin Control Shutdown
"E" and "G" Control Board with Thermostatic Bin Control Shutdown Sequence Flow Chart
Legend:
BC–bin control
TBC–themostatic bin control
To Next Page
