Hotone Ampero Operating Guide

1
DES I GN IN S PIRAT ION
1. In the main menu, click “GLOBAL” and then “EXP2/FS. Set “MODE” to “Dual FS” in the selection panel.
TRS
1/4"(6.35mm)StereoCable
Preface
This operating guide is for how to set the Ampero Switch on Ampero or Ampero One. On both units, Ampero Switch is connected and set in the
same way, so the following steps will take Ampero as an example.
If you want to set the Ampero Switch to control other device, please refer to the related contents of your device manual.
How to connect
Connect one end of the TRS jack to Ampero Switch and the other end to the EXP 2 / FS jack of Ampero with the provided TRS cable.
How to set up

Hotone Ampero Specifications

Audio Processing

digital audio signal processing bit depth	24-bit
digital audio signal processing sample rate	44.1kHz
signal-to-noise ratio	120dB

Effects and Patches

effects	242
effects modules	Total of 9 simultaneous
patches	198 (99 user patches, 99 factory patches)

Looper and Drum Machine

looper time mono	100 seconds
looper time stereo	50 seconds
internal drum machine rhythm patterns	100

Inputs

instrument jack	One 1/4” Tip Sleeve (TS)
auxiliary input jack	One 1/8” Stereo
expression pedal input jack	One 1/4” Tip Ring Sleeve (TRS)

Outputs

unbalanced stereo output jacks	Two 1/4” Tip Sleeve (TS)
balanced stereo output jacks	Two XLR
headphones output jack	One 1/8” Stereo

Resistance

instrument input resistance	E.GT: 1MΩ; A.GT: 4.7MΩ; LINE: 10kΩ
aux in resistance	10kΩ
output resistance unbalanced	3.2kΩ

Display and Connectivity

screen size	4”
display resolution	800 x 480
usb port	USB 2.0 Type-B

Power

power requirements	18V DC Center Negative
current consumption	500mA Max
weight	1408g

Dimensions

length	320mm
width	147mm
height	46mm
