HOTSY 965SS-1075SS • 9.807-621.0 • Rev. 09/18
27
PRESSURE WASHER
OPERATOR’S MANUAL
Replacement Parts
For best performance specify genuine WAYNE replacement parts
WAYNE BURNER PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 101415-001 Tube/Hous-101407-001/3A/.88I 1
2 30537-031 Gun-RG/*CST/GBB 1
3 101128-011 Pump-s A2VA3006-N261 12V Combo 1
4 14451 Oil Line ASM-6" 1
11 13392 Plate, Slot Cover 1
12 14296 Nut, Hex 3/8-24 CRZC 1
15 2669-002 Band, Air-Inner E/FH 1
16 2668-002 Band, Air-Outner 8-Hole E/F 1
18 31953-001 sPost, contact-Allason 2
23 13074-003 Cover, Juntion Box 1
26 24007-001 Motor, 13.5VDC-Ametek 1
27 23200 Cover, Hous-E 12V 1
28 101308-001 Ignitor-CC 6385 12VDC 4.8A 1
29 101309-002 Base, Mounting-Ignitor CC Timer 1
30 100889-002 Timer, Ignitor-12V AH1501 1
35 14289 sCAD, Cell-H 15" LEAD/17* BRKT 1
37 23022-001 sFan-3.44"W X 4.75"D 5/16" Bore 1
38 101320-001 sCoupling-Mod E 12VDC 1
50 12484 *Gasket, Flange-STD Large 2
sNot Shown
*Packed with burner
