HOTSY 965SS-1075SS • 9.807-621.0 • Rev. 09/18
35
PRESSURE WASHER
OPERATOR’S MANUAL
HP3035G1 SERIES PUMP EXPLODED VIEW PARTS LIST
REPAIR KIT
NUMBER 8.754-860.0 8.754-861.0 8.754-862.0 8.754-859.0 9.803-937.0
KIT DESCRIP-
TION
Plunger Seal
15mm
Complete
Seal Packing 15mm Plunger 15mm Complete Valve
Plunger Oil
Seals
ITEM NUM-
BERS
INCLUDED
4, 6, 8 4, 5, 6, 7, 8, 43, 44, 45, 46 12, 13, 14, 3
NUMBER OF
CYLINDERS KIT
WILL SERVICE
3 1 1 6 3
ITEM PART NO. DESCRIPTION QTY
37 9.803-244.0 Screw 4
38 89.803-217.0 Washer 4
39 9.803-216.0 Washer 4
40 8.752-824.0 Screw, M6 x 20 4
41 9.803-218.0 Washer, 6 mm 10
42 8.754-864.0 Flange, Engine 1
43* 8.754-855.0 Bolt, Plunger 3
44* 8.754-092.0 Spacer, Copper 3
45* 8.754-849.0 Plunger, 14 mm 3
46* 9.803-962.0 Spacer, Copper 3
47 8.754-827.0 Plunger Rod 3
48 9.803-965.0 Connecting Rod Pin 3
49 9.803-966.0 Connecting Rod 3
50 8.933-020.0 Screw, Connecting Rod 6
51 8.754-847.0 O-ring Ø2.62 X 111.62 1
52 8.754-842.0 Cover, Crankcase 1
53 9.803-906.0 O-ring Ø1.78 X 14 1
54 9.803-202.0 Sight Glass, G3/4 1
* Available in kit (See below)
