29Hotsy 1700 Operator’s Manual 8.914-380.0 - W
HB Series Pump Exploded View Parts List
REF PART NO. QTY DESCRIPTION NOTES
21 8.707-262.0 2 PLUG, BRASS G3/8
22 - 6 VALVE SEAT SEE KITS TABLE
23 - 6 VALVE PLATE SEE KITS TABLE
24 - 6 VALVE SPRING SEE KITS TABLE
25 - 6 VALVE CAGE SEE KITS TABLE
26 9.802-939.0 12 SCREW, M6 X 16
27 8.717-137.0 2 BEARING COVER
28 9.803-954.0 1 BEARING SEAL
29 8.754-843.0 2 SEAL SPACER, CRANKSHAFT
30 9.802-914.0 1 SNAP RING, 25 MM
31 9.803-955.0 2 BEARING, BALL
32 8.754-829.0 1 SHAFT, 24 MM 3030
- 8.754-830.0 1 SHAFT, 24 MM 4025
33 9.803-167.0 1 KEY, CRANKSHAFT
34 8.754-219.0 1 OIL DIPSTICK
35 8.933-010.0 1 SEAL, CRANKSHAFT
36 8.754-855.0 3 BOLT, PLUNGER SEE KITS TABLE
37 8.754-092.0 3 SPACER, COPPER SEE KITS TABLE
38 8.754-848.0 3 PLUNGER, 16 MM SEE KITS TABLE
39 9.803-962.0 3 SPACER, COPPER SEE KITS TABLE
40 8.754-827.0 3 PLUNGER ROD
41 9.803-965.0 3 CONNECTING ROD PIN
42 9.803-966.0 3 CONNECTING ROD
43 9.803-218.0 6 WASHER, 6 MM
44 8.933-020.0 6 SCREW, CONNECTING ROD
45 8.754-847.0 1 O-RING Ø2.62 X 111.62
46 8.754-842.0 1 COVER, CRANKCASE
47 9.803-906.0 1 O-RING Ø1.78 X 14
48 9.803-202.0 1 SIGHT GLASS, G3/4
KIT NUMBERS 8.754-856.0 8.754-857.0 8.754-858.0 8.754-859.0 9.803-937.0
KIT DESCRIPTION
Plunger Seals 16
mm
Seal Packing 16
mm
Plunger 16 mm
Complete
Valve
Plunger Oil
Seals
ITEM NUMBERS
INCLUDED
4, 6, 8 4, 5, 6, 7, 8 36, 37, 38, 39 12, 13, 14 3
NUMBER OF
CYLINDERS KIT
WILL SERVICE
31163
